BCZ85 SERIES EXPLOSION PROOF PLUG AND SOCKETS

BCZ85-16

Proteksi ledakan

Proteksi gas

II 2 G Ex  d IIC T6 Gb

Proteksi debu

II 2 D Ex t IIIC T80C IP66

Sertifikat

Nemko 12 ATEX 1044; IECEx CQM  12.0015,

KZ.7500525.22.01.00363 (CU-TR)

Kesesuaian dengan standar

EN 60079-0, EN 60079-1, EN 60079-31

IEC 60079-0, IEC 60079-1, IEC 60079-31

material

Copper Free alumunium, Power coated surface

Exposed fastener

Stainless stell

Voltasi

Max. 690V AC

Amper

16A

Number of pole

3P (2P+PE), 4P(3P+PE), 5P (3P+N+PE)

Tingkat Proteksi

IP65, IP67 opsional

Earthing

M5/M5

Suhu Ruangan

-60°C~ +55°C

Cable entry of socket

2XM25 X1,5(3P/4P), 2XM32X1,5(5P)

cable entry of plug

1XM25 X1,5(3P/4P), 1XM32X1,5(5P)

Cable gland

DQM-II (Ex d) atau DQM-III (Ex d) rekomendasi

Cross section of cable

2.5~4mm

BCZ85-32

Proteksi ledakan

Proteksi gas

II 2 G Ex  d IIC T6 Gb

Proteksi debu

II 2 D Ex t IIIC T80C IP66

Sertifikat

Nemko 12 ATEX 1044; IECEx CQM  12.0015,

KZ.7500525.22.01.00363 (CU-TR)

Kesesuaian dengan standar

EN 60079-0, EN 60079-1, EN 60079-31

IEC 60079-0, IEC 60079-1, IEC 60079-31

material

Copper Free alumunium, Power coated surface

Exposed fastener

Stainless stell

Voltasi

Max. 690V AC

Amper

326A

Number of pole

3P (2P+PE), 4P(3P+PE), 5P (3P+N+PE)

Tingkat Proteksi

IP65, IP67 opsional

Earthing

M5/M5

Suhu Ruangan

-60°C~ +55°C

Cable entry of socket

2XM25 X1,5

cable entry of plug

1XM25 X1,5

Cable gland

DQM-II (Ex d) atau DQM-III (Ex d) rekomendasi

Cross section of cable

4~6mm

BCZ85-63

Proteksi ledakan

Proteksi gas

II 2 G Ex  d IIC T6 Gb

Proteksi debu

II 2 D Ex t IIIC T80C IP66

Sertifikat

Nemko 12 ATEX 1247; IECEx CQM  12.0043X,

KZ.7500525.22.01.00363 (CU-TR)

Kesesuaian dengan standar

EN 60079-0, EN 60079-1, EN 60079-31

IEC 60079-0, IEC 60079-1, IEC 60079-31

material

Copper Free alumunium, Power coated surface

warna

Abu-abu (RAL7040)

Exposed fastener

Stainless stell

Voltasi

Max. 690V AC

Amper

63A

Number of pole

4P (3P+PE), 5P (3P+N+PE)

Tingkat Proteksi

IP65, IP67 opsional

Earthing

M6/M6

Suhu Ruangan

-60°C~ +55°C

Cable entry of socket

2XM25 X1,5

cable entry of plug

1XM25 X1,5

Cable gland

DQM-II (Ex d) atau DQM-III (Ex d) rekomendasi

Cross section of cable

10~16mm

BCZ85-125

Proteksi ledakan

Proteksi gas

II 2 G Ex  d IIC T6 Gb

Proteksi debu

II 2 D Ex t IIIC T80C IP66

Sertifikat

Nemko 13 ATEX 1353; IECEx CQM  13.0033X,

KZ.7500525.22.01.00363 (CU-TR)

Kesesuaian dengan standar

EN 60079-0, EN 60079-1, EN 60079-31

IEC 60079-0, IEC 60079-1, IEC 60079-31

material

Copper Free alumunium, Power coated surface

warna

Abu-abu (RAL7040)

Exposed fastener

Stainless stell

Voltasi

Max. 690V AC

Amper

125A

Number of pole

4P (3P+PE), 5P (3P+N+PE)

Tingkat Proteksi

IP65, IP67 opsional

Earthing

M6/M8

Suhu Ruangan

-60°C~ +55°C

Cable entry of socket

2XM63 X1,5

cable entry of plug

1XM50 X1,5

Cable gland

DQM-II (Ex d) atau DQM-III (Ex d) rekomendasi

Cross section of cable

25~35mm
